Forged ball valve
PRODUCT SPECIFICATIONS
| DESIGN |
|---|
| ASME B16.34 |
| API 6D, API 608 |
| BS 5351 |
| JIS B 2071 |
| STRUCTURE |
|---|
| SIDE ENTRY |
| TOP ENTRY |
| RATING |
|---|
| CLASS 150 / JIS 10K |
| CLASS 300 / JIS 20K |
| CLASS 600 / JIS 40K |
| JIS 30K |
| CLASS 800 / 900 / 1500 / 2500 |
| SIZE |
|---|
| 1/2" ~ 48" / 15 ~ 1,200 |
| 1/2" ~ 48" / 15 ~ 1,200 |
| 1/2" ~ 48" / 15 ~ 1,200 |
| 15 ~ 1,200 |
| 1/2" ~ 36" / 1/2" ~ 24" / 1/2" ~ 12" |
| APPLICATIONS |
|---|
| Chemical and Pharmaceutical Industry |
| Oil and Gas Industry |
| Power Plants |
| Marine and Offshore Plants |
| General Heavy and Industrial Applications |
| END CONNECTION |
|---|
| ASME B16.5 |
| ASME B16.47 |
| ASME B16.25 |
| DIN EN 1092-1 / JIS B 2220 |
| RF / FF / RTJ / BW / SPECIAL |
| FACE TO FACE |
|---|
| ASME B16.10 |
| API 6D |
| JIS B 2002 |
| KS B 2308 |
| MANUFACTURE'S STANDARD |
| TEST |
|---|
| API 598 |
| JIS B 2003 |
| BODY MATERIAL |
|---|
| Carbon Steel |
| Stainless Steel |
| Duplex Stainless Steel |
| Super Duplex Stainless Steel |
| Monel / Alloy 625 / B148-C95800 |
| SEAT MATERIAL |
|---|
| PTFE |
| RTFE (Glass, Graphite, Carbon) |
| RTFM |
| DEVLON / PEEK |
| SPECIAL |
| BORE |
|---|
| FULL BORE |
| REDUCER BORE |
| FEATURES |
|---|
| High Strength and Pressure Resistance |
| Excellent Durability and Corrosion Resistance |
| Robust Sealing Performance |
| Quick Operation |
| Diverse Materials and Specifications |
